CF120 PLUS-3 IN 1
Overflowing Light
LIGHT UP YOUR BUILD
The CF120 PLUS case fan fits 18 individual addressable RGB LEDs across the fan blades and housing to create vibrant lighting effects in a layered design.
RGB CONTROLLER
Easily switch between 6 preset lighting effects with the included RGB controller. Customize to fit with your color settings.
Double Click to Switch
-Full RGB/ Halo Only
-Full RGB/ Halo Only
Hold for 3 seconds to Switch
-RGB ON/Off
-RGB ON/Off
MOTHERBOARD RGB SYNC
Sync with your motherboard for direct control using RGB software, including Chroma.
KEEPING THINGS COOL
Maximize cooling efficiency with powerful fan speeds and PWM fan control to quickly lower system temperatures when needed and staying quiet under light loads.
500~1800 RPM±10%
Wide Speed Range
52.5 CFM
Ultra Airflow
≤28.8 dB(A)
Super Silent
WHATS IN THE BOX
-
5V A-RGB Wire Controller
-
4 Ports PWM Hub
-
Screws
Technical Spec
| Fan Dimension | 120×120×26.5 mm(L×W×H) |
| Net Weight | 569g |
| FAN Speed | 500~1800 RPM±10% |
| Fan Air Flow | 52.5 CFM |
| Fan Air Pressure | 2.08 mmAq |
| Fan Noise Level | ≤28.8 dB(A) |
| Fan Connector | 4-Pin PWM |
| FAN Rated Voltage | 12VDC |
| FAN Rated Current | 0.18A |
| FAN Power Consumption | 2.16W |
| LED Type | Addressable RGB LED |
| LED Rated Voltage | 5VDC |
| LED Rated Current | 0.63A |
| LED Rated Power | 3.15W |
| LED Connector | 3-pin（+5V-D-G） |
| EAN | 6933412710509 |
| P/N | DP-F12-AR-CF120P-3P |
Product Dimension
Download
CF120 PLUS-3 IN 1 Manual.pdf
