Specifications
Sequential read up to 7400MB/s, sequential write up to 6500MB/s
Sequential read up to 7400MB/s, sequential write up to 6500MB/s
High-speed Performance
PCIe Gen4x4 Interface
NVMe 2.0 Technology Standard3
The latest 12nm Controller
Specifications
Capacities
512GB/1TB/2TB/4TB
Form Factor
M.2 2280
Interface
PCIe Gen4x4
Speed
512GB—Sequential read up to 7200MB/s, sequential write up to 4400MB/s¹
1TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
2TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
4TB—Sequential read up to 7400MB/s, sequential write up to 6500MB/s¹
Operating Temperature
0°C to 70°C (32°F to 158°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Dimensions (L x W x H)
80 x 22 x 2.45 mm (3.15” x 0.87” x 0.10”)
Weight
6g / 0.013 lbs
Warranty
Five-year limited warranty
Shock-resistant
1500G, duration 0.5ms, Half Sine Wave
Vibration-resistant
10~2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X,Y,Z)
TBW
512GB: 500TBW, 1TB: 1000TBW, 2TB: 1500TBW,4TB：3000TBW
MTBF
1,500,000 Hours
1Up to 7400MB/s read transfer, write transfer speeds lower. Speeds based on internal testing. Actual performance may vary.
2Comparison based on internal testing. Actual performance may vary.
34TB support NVMe 2.0 technology standard,512GB-2TB support NVMe 1.4 technology standard
Security safeguards, by their nature, are capable of circumvention. Lexar does not guarantee data will be 100% secure from unauthorized access, alteration, or destruction.
Actual usable memory capacity may vary. 1GB equals 1 billion bytes.
Lexar is not liable for any loss of data or images.
Product Numbers
